中空玻璃的組成部分：
Components of insulating glass:
1、邊緣密封系統。在目前國際市場上，公認的中空玻璃邊緣密封系統有兩種：一種是傳統的冷邊密封系統（槽鋁式），一種是以美國Swiggle膠條為代表的暖邊密封系統（復合膠條式）。由于傳統鋁槽式中空玻璃產品在國際和國內應用的時間較長，因而被很多人認可，而暖邊系統1997年才開始在國內推廣，產品還沒有被人們廣泛認識。
1. Edge sealing system. In the current international market, there are two recognized insulating glass edge sealing systems: one is the traditional cold edge sealing system (slot aluminum type), and the other is the warm edge sealing system (composite adhesive strip type), represented by American swiggle adhesive strip. Because the traditional aluminum trough insulating glass products have been used for a long time at home and abroad, they have been recognized by many people. However, the warm edge system was only promoted in China in 1997, and the products have not been widely recognized.
2、空間間隔層和氣體。在中空玻璃的間隔層中，為了保證中空玻璃的性能，間隔層氣體是干燥的。內部氣體可以是干燥空氣、氬氣或其他特殊氣體。
2. Space compartments and gases. In the spacer layer of insulating glass, firstly, in order to ensure the performance of insulating glass, the gas in the spacer layer is dry. The internal gas can be dry air, argon or other special gases.
3、構成中空玻璃的原片玻璃。這些玻璃可以是普通玻璃、夾層玻璃、陽光控制玻璃等等。由于采用的原片玻璃不同，中空玻璃的作用及使用地點也可以不同。而且由于要求不同，可以采用兩層，三層或多層原片玻璃。
3. The original sheet glass that forms the insulating glass. These glasses can be ordinary glass, laminated glass, sunlight control glass, etc. Due to the different original glass, the function and place of use of insulating glass can also be different. Moreover, due to different requirements, two, three or more layers of original glass can be used.
中空玻璃的生產流程：
Production process of insulating glass:
整個中空玻璃的加工流程簡單的描述就是玻璃裁切→磨邊→清洗干燥→制框→灌裝干燥劑→涂布丁基膠→上框→合片壓片→封膠→固化。看似過程十分的簡單并且中空玻璃的制作也十分的輕松，但是在我們實際生產操作中也是十分需要技術和耐心的。
The simple description of the whole insulating glass processing process is glass cutting → edging → cleaning and drying → frame making → filling desiccant → coating butyl rubber → upper frame → closing and pressing → sealing → curing. It seems that the process is very simple and the production of insulating glass is also very easy, but it also needs technology and patience in our actual production and operation.

關于充氣中空玻璃的生產控制：
Production control of inflatable insulating glass:
充氣中空玻璃的生產過程控制概念是，為確保充氣中空玻璃生產過程處于受控狀態，對影響充氣濃度質量的生產過程所采取的作業技術和生產過程的分析、診斷和實時監控。它的作用在于對生產過程的質量控制進行系統安排，對直接或間接影響過程質量的因素進行**控制并制定實施控制計劃，確保過程質量。氬氣是無色無味氣體，其充氣濃度不易測量。目前的測試方法大體可以分為兩種：
The production process control concept of inflatable insulating glass is the analysis, diagnosis and real-time monitoring of the operation technology and production process that affect the quality of inflatable concentration in order to ensure that the production process of inflatable insulating glass is under control. Its role is to systematically arrange the quality control of the production process, control the factors that directly or indirectly affect the process quality, and formulate and implement the control plan to ensure the process quality. Argon is a colorless and odorless gas, and its inflation concentration is difficult to measure. The current testing methods can be roughly divided into two types:
（1）傳感器對從排氣孔所收集的氣體與所設置的氣體濃度相比較，以判斷是否達到要求。
(1) The sensor compares the gas collected from the exhaust hole with the set gas concentration to judge whether it meets the requirements.
（2）傳感器對排氣孔所收集的氣體與所設置的氣體濃度進行動態比較并給出濃度、氣壓和流速等實時曲線，不但從濃度上判斷而且從曲線形狀上判斷，充氣的實際濃度。
(2) The sensor dynamically compares the gas collected by the exhaust hole with the set gas concentration and gives the real-time curves of concentration, pressure and flow rate. It can judge the actual concentration of inflation not only from the concentration but also from the curve shape.
二者相比，由于-*二種方法不僅僅是兩個值的比較，而是對整個充氣過程的描述，是目前充氣過程實時監控的的生產控制手段。
Compared with the two, the - * two methods are not only the comparison of two values, but also the description of the whole inflation process. They are advanced production control means for real-time monitoring of the inflation process at present.
以上就是為大家介紹的有關中空玻璃生產線的詳細的介紹,希望對您有所幫助.如果您有什么疑問的話,歡迎聯系我們.我們將以的態度,為您提供服務http://m.hebeiruizhi.com
The above is a detailed introduction about the insulating glass production line. I hope it will be helpful to you If you have any questions, please contact us We will provide you with professional service http://m.hebeiruizhi.com
